产品详情
带微动装置；
不锈钢制造或碳钢制造；
货号(不锈钢） Item NO（Stainless Steel） | 货号(碳钢） Item NO（Carbon Steel） | 测量范围 Range mm | 读数值 Verier mm | A mm | B mm | C mm | D mm |
| ST194CS-505 | ST194CC-812 | 0-300 | 0.05 | 60/90 | 10 | 10 | 18.5 |
| ST194CS-205 | ST194CC-205 | 0.02 | 60/90 | 10 | 10 | 18.5 | |
| ST194CS-605 | ST194CC-605 | 0-300/0-12″ | 0.05/1/128″ | 60/90 | 10 | 10 | 18.5 |
| ST194CS-805 | ST194CC-805 | 0.02/0.001″ | 60/90 | 10 | 10 | 18.5 | |
| ST194CS-506 | ST194CC-506 | 0-400 | 0.05 | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-206 | ST194CC-206 | 0.02 | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-606 | ST194CC-606 | 0-400/0-16″ | 0.05/1/128″ | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-806 | ST194CC-806 | 0.02/0.001″ | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-507 | ST194CC-507 | 0-450 | 0.05 | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-207 | ST194CC-207 | 0.02 | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-607 | ST194CC-607 | 0-450/0-18″ | 0.05/1/128″ | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-807 | ST194CC-807 | 0.02/0.001″ | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-508 | ST194CC-508 | 0-500 | 0.05 | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-208 | ST194CC-208 | 0.02 | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-608 | ST194CC-608 | 0-500/0-20″ | 0.05/1/128″ | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-808 | ST194CC-808 | 0.02/0.001″ | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-509 | ST194CC-509 | 0-600 | 0.05 | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-209 | ST194CC-209 | 0.02 | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-609 | ST194CC-609 | 0-600/0-24″ | 0.05/1/128″ | 90/125/150 | 10 | 12 | 23/25 |
| ST194CS-809 | ST194CC-809 | 0.02/0.001″ | 90/125/150 | 10 | 12 | 23/25 | |
| ST194CS-510 | ST194CC-510 | 0-800 | 0.05 | 125/150/200 | 20 | 20 | 30/32 |
| ST194CS-210 | ST194CC-210 | 0.02 | 125/150/200 | 20 | 20 | 30/32 | |
| ST194CS-610 | ST194CC-610 | 0-800/0-80″ | 0.05/1/128″ | 125/150/200 | 20 | 20 | 30/32 |
| ST1194CS-810 | ST194CC-810 | 0.02/0.001″ | 125/150/200 | 20 | 20 | 30/32 | |
| ST194CS-511 | ST194CC-511 | 0-1000 | 0.05 | 125/150/200 | 20 | 20 | 30/32 |
| ST194CS-211 | ST194CC-211 | 0.02 | 125/150/200 | 20 | 20 | 30/32 | |
| ST194CS-611 | ST194CC-611 | 0-1000/0-40″ | 0.05/1/128″ | 125/150/200 | 20 | 20 | 30/32 |
| ST194CS-811 | ST194CC-811 | 0.02/0.001″ | 125/150/200 | 20 | 20 | 30/32 | |
| ST194CS-512 | ST194CC-512 | 0-1500 | 0.05 | 200/250/300 | 20 | 20 | 50 |
| ST194CS-212 | ST194CC-212 | 0.02 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-612 | ST194CC-612 | 0-1500/0-60″ | 0.05/1/128″ | 200/250/300 | 20 | 20 | 50 |
| ST194CS-812 | ST194CC-812 | 0.02/0.001″ | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-513 | ST194CC-513 | 0-2000 | 0.05 | 200/250/300 | 20 | 20 | 50 |
| ST194CS-213 | ST194CC-213 | 200/250/300 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-613 | ST194CC-613 | 0-2000/0-80″ | 0.05/1/128″ | 200/250/300 | 20 | 20 | 50 |
| ST194CS-813 | ST194CC-813 | 200/250/300 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-514 | ST194CC-514 | 0-2500 | 0.05 | 200/250/300 | 20 | 20 | 50 |
| ST194CS-214 | ST194CC-214 | 200/250/300 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-614 | ST194CC-614 | 0-2500/0-100″ | 0.05/1/128″ | 200/250/300 | 20 | 20 | 50 |
| ST194CS-814 | ST194CC-814 | 200/250/300 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-515 | ST194CC-515 | 0-3000 | 0.05 | 200/250/300 | 20 | 20 | 50 |
| ST194CS-215 | ST194CC-215 | 0.02 | 200/250/300 | 20 | 20 | 50 | |
| ST194CS-615 | ST194CC-615 | 0-3000/0-120″ | 0.05/1/128″ | 200/250/300 | 20 | 20 | 50 |
| ST194CS-815 | ST194CC-815 | 0.02/0.001″ | 200/250/300 | 20 | 20 | 50 |
